Water Heater/Low Pressure Solar Water Heater

FOB Reference Price:Get Latest Price
US $80-350 / Sets | 1 Set/Sets AS SAMPLE (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Type:
Evacuated Tube, Non pressurized
Pressure:
Unpressurized
Circulation Type:
Direct / Open Loop (Active)
Heating System:
Thermosyphon (Passive)
Connection Type:
Direct-Plug
Installation:
Freestanding
Housing Material:
Stainless Steel
Certification:
CE, CCC,ISO
Capacity:
200, from 110L to 360L
Place of Origin:
Zhejiang, China (Mainland)
Brand Name:
EJAI/OEM
Model Number:
YYJ-R03
Product Name:
Solar Water Heater
Warranty:
5 years
Application:
hot water, bath, shower, washing
SupplyAbility
SupplyAbility:
8000 Set/Sets per Month
Packaging & Delivery
Packaging Details
Standard Export Packing,Wooden Packing for Sample
Port
Shanghai/Ningbo
Lead Time :
With 15 days

Specifications

Solar Water Heater:
1.Economic non pressure system
2.SUS304 Inner tank
3.CCC,CE,ISO
4.delivery:10-15days

Water Heater/Low Pressure Solar Water Heater

CHARACTERISTICS:

1. It takes advantage of the tap water’s pressure. More pressure more comfortable.

2. The water is heated in short time and meeting your demand for hot water.

3. It can produce more hot water than the general types with continuous hot water coming.

Water Heater/Low Pressure Solar Water Heater

keymark:

Inner tank: Imported stainless steel (SUS304/2B), 0.4mm thickness

Outer tank: Imported stainless steel (SUS304 2B, 0.4mm thickness

Bracket: Stainless steel, 1.2mm thickness

Heat insulation layer: Imported polyurethane (Bayer, Germany), 50mm thickness

Working temperature: 99 celsius degree

Working pressure: 0.005Mpa (0.05 bars)

Accessory: Optional assistant tank and electrical heater

Warranty: 1 year for electric parts/5 Years for the full system /15 Years for the vacuum tube



Item No.

Solar Vacuum Tube

Absorber     Area(m2)

Tank          Capacity

Loading Qty / sets

pcs

size / mm

20GP/40GP/40HQ

YYJ-R031-18

18

Φ47 X 1500

1.69

110L

58/129/144

YYJ-R031-20

20

Φ47 X 1500

1.88

130L

53/118/133

YYJ-R031-24

24

Φ47 X 1500

2.26

160L

43/97/108

YYJ-R031-30

30

Φ47 X 1500

2.83

200L

35/77/87

YYJ-R031-36

36

Φ47 X 1500

3.40

250L

30/68/75



YYJ-R032-15

15

Φ58 X 1800

1.97

150L

43/86/100

YYJ-R032-18

18

Φ58 X 1800

2.36

180L

39/82/96

YYJ-R032-20

20

Φ58 X 1800

2.62

200L

34/72/84

YYJ-R032-24

24

Φ58 X 1800

3.15

240L

31/65/77

YYJ-R032-30

30

Φ58 X 1800

3.95

300L

22/50/58

YYJ-R032-36

36

Φ58 X 1800

4.75

360L

16/40/43



Water Heater/Low Pressure Solar Water Heater

Remark:

1. Diameter of the tank: 360/460mm

2. Insulation thickness: 50mm

2. Vent connection: 1/2"

4. Electric heater connection: 47mm

5.Cold water inlet: 1/2"

6. Hot water outlet:3/4"

7. Installation angel: 30/45
