Pre-heated Copper Coil Solar Water Heater with Three Target Vacuum Tube

FOB Reference Price:Get Latest Price
US $100-600 / Sets | 1 Set/Sets as sample (Min. Order)
Contact Supplier
Loading...
Report Suspicious Activity
Overview
Quick Details
Type:
Evacuated Tube, Evacuated Tube
Pressure:
Unpressurized
Circulation Type:
Direct / Open Loop (Active)
Heating System:
Batch / ICS (Passive)
Connection Type:
Direct-Plug
Installation:
Freestanding
Housing Material:
Stainless Steel, color steel
Certification:
CE, CCC, ISO 9001
Capacity:
200
Place of Origin:
Zhejiang, China (Mainland)
Brand Name:
EJAI or OEM
Model Number:
YYJ-P01
Product Name:
Solar Water Heater
Use:
solar water heating,swimming pool,bathing,thermal heating
Pipe Material:
Glass + Copper
Inner tank:
SUS304 Stainless steel
Outer tank:
Galvanized Steel/Stainless steel
Guarantee:
5 years for whole system/15 years for vacuum tube
Delivery Time:
Within 15 days after receiving deposit
Supply Ability
Supply Ability:
8000 Set/Sets per Month
Packaging & Delivery
Packaging Details
Standard export carton for full container Wooden packing for samples
Port
Shanghai / Ningbo
Lead Time :
7-15 days

Specifications

Solar Water Heater:
1.For 5years warranty
2.CCC,CE,ISO,KEYMARK,approved
3.OEM is welcomed

Pre-heated Copper Coil Solar Water Heater with Three Target Vacuum Tube CHARACTERISTICS:



1. Instant heat exchange to provide plentiful warm water

2. Fresh and high water quality

3. Working with pressure

4. Output water temperature is stable, so it is very comfortable and safe to use

5. Hot&cold water flow is separated

6. Copper coil is tested and does not break

7. Works intelligently and easy and is very reliable

8. Perfect performance



Pre-heated Copper Coil Solar Water Heater with Three Target Vacuum Tube Material:

Inner tank: Imported stainless steel (SUS304/2B), 0.5mm thickness

Outer tank: Galvanized steel alloy,0.4mm thickness

Bracket: Galvanized steel alloy, 1.5mm thickness

Heat insulation layer: Imported polyurethane (Bayer, Germany), 50mm thickness

Working temperature: 99 celsius degree

Working pressure: Copper coil: above 0.6Mpa (6 bars), tank: 0.005Mpa (0.05 bars)

Copper coil: 12mm, 0.8mm thickness

Warranty: 1 year for electric parts/5 Years for the full system /15 Years for the vacuum tube



Pre-heated Copper Coil Solar Water Heater with Three Target Vacuum Tube Remark:

1. Diameter of the tank: 360/460mm

2. Insulation thickness: 50mm

3. Coil connection: 1/2"

4. Electric heater connection: 1"

5.Cold water inlet: 1/2"

6. Installation angel: 30/45



Pre-heated Copper Coil Solar Water Heater with Three Target Vacuum Tube:
